Savin SP 8400DN

Manufacturing Status: Current
Part Number: 408244

Domestic Intro Date: June 2017
SRP/Street Price: $3,059/None
Also Sold As: Ricoh SP 8400DN; Savin SP 8400DN
Predecessor Model: Savin SP 8300DN
Replacement Model:
Replacement Date:
Color Type: Not applicable
Controller: Ricoh
CPU/Bits/MHz: Intel Atom Processor Bay Trail-I/INA/1.46 GHz
Memory (std/max): 2 GB/2 GB
HDD/Storage: Optional 320-GB
PDLs: PCL 5e/6, RPCS, PostScript 3, opt Adobe PostScript 3, opt IPDS, opt XPS
Warm-up Time: 21 sec
First-Page-Out Time (Mono/Color): 2.2 sec
Mfr/Model/Country: Ricoh/SP 8400DN/Thailand
Monthly Duty Cycle: 300,000 impressions
Rated Engine Life: 3,200,000 impressions
Recommended Monthly Volume: 200,000 impressions
Standard: 1200 x 1200 dpi
Enhanced: INA
Client OS Support: Windows Vista/Server 2008/7/Server 2012/8.1/10, Mac OS X v10.9+, Citrix, Linux, UNIX
Network Spt: Windows, Mac, Linux, UNIX
Std Interface: 10/100/1000BaseT Ethernet
Opt Interface: 802.11a/b/g/n, Parallel, USB 2.0, USB 2.0 (host) x 3
Printer Mgmt: INA
Near Field Communication: Standard
Embedded Software Platform or Extensible Solutions Interface: Not applicable
Smart Operation Panel offers smart device look and feel, along with standard web browsing; Workstyle Innovation Technology allows users to select from a wide range of smart apps on the user interface; How To video app available for help guidance; supports mobile and cloud printing (Google Drive, Box and Dropbox); opt PB3240 paper-feed unit has two 550-sheet drawers; opt LCIT PB3260 2,000-sheet A4/8-1/2″ x 11″ LCT; opt LCIT RT3030 1,500-sheet A4/8-1/2″ x 11″ side LCT; opt SR3210 hybrid staple and stapleless finisher has two trays (250/1,000), 50 sheet stapling and stapleless finishing (by perforating and pressing together) up to five sheets; opt SR3230 stapler finisher has two trays (250/3,000) with 50-sheet stapling; opt punch units; opt four-bin mailbox; opt FD3000 folding unit features Z-, half-, outer tri- and inner tri-folds
Paper Handling
Std/Max Paper Source(s): 3/6
Std/Max Paper Capacity: 1,200 sheets/4,700 sheets
Paper Size (WxL): 12″ x 17″ max
Print Area (WxL): INA max
Paper Weights: 16-lb to 82-lb bond, 170-lb index
Std Output Capacity: 500 sheets
Other Ouput: Optional finishers
Bypass (Capacity/Weight): 100 sheets/14-lb to 82-lb bond, 170-lb index
Automatic Duplexing: Standard
Collation: Standard
Color Depth (Bits): Not applicable
Color Management: Not applicable
Fonts: 93 PCL/PS
IPP (Web) Support: Standard
RIP Once/Print Many: Standard
Other: PDF direct print – opt XPS direct print; SD and USB file formats supported include JPEG, PDF, TIFF and XPS; N-up printing; booklet printing; watermarks; poster printing; banner pages; covers; chapterization; toner-save mode; one-touch shortcuts; feeds sizes up to 560 mm/23.62″
Security Specs
Network User Authentication: Yes
IP Address Filtering: Yes
MAC Address Filtering: No
HDD Overwrite: Optional
Max Overwrites: 3
HDD Encryption: Optional
Secure Print: Standard
Encrypted Secure Print: INA
IPsec: Yes
Secure Sockets Layer (SSL): Yes
SNMPv3: Yes
Transport Layer Security: Yes
Other: DataOverwriteSecurity and hard drive encryption with optional hard drive; wireless LAN security (WPA/EEE802.11i/w); compulsory security stamp
Additional Information
Display/Characters: 10.1″ color touchscreen/NA
Energy Star Compliance: Yes
Noise Level (Print/Idle): 52.5 dB/INA
Energy Used While Power Off: INA
Energy Used in Power Save Mode: 0.79W
Energy Used in Ready Mode: 38.6W
Energy Used While Printing: 789.5W
Max Power Consumption: 1600W
TEC Value: 2.6KWh
Power Req’s (V/Hz/Amps): 120-127/50-60/12
Warranty: One-year
Weight (Base Unit): 125.6 lbs
Dimensions (HxWxD): 28.3″ x 23.1″ x 25.7″
