Manufacturing Status: |
Current |
Part Number: |
KV-S5046H |
Market Segment: |
Departmental |
SRP: |
$5,195 |
Domestic Intro Date: |
January 2014 |
Engine Manufacturer: |
Panasonic |
Also Sold As: |
None |
Predecessor Model: |
Panasonic KV-S5055C |
Replacement Model: |
|
Replacement Date: |
|
Daily Duty Cycle: |
25,000 pages |
TECHNOLOGY
Scanner Technology: |
CIS |
Light Source: |
LED |
PAPER HANDLING
Flatbed Maximum Scanning Area: |
Not applicable |
ADF: |
Standard |
Capacity: |
300 |
Minimum Original Size: |
1.9″ x 2.75″ |
Maximum Original Size: |
11.7″ x 100″ |
Paper Weights: |
5 – 42 lbs |
Maximum Paper Thickness: |
0.008″ |
SPEED (PORTRAIT/LANDSCAPE; 200 DPI)
Black: |
|
Simplex: |
60 ppm/80 ppm |
Duplex: |
120 ipm/160 ipm |
Color: |
|
Simplex: |
60 ppm/80 ppm |
Duplex: |
120 ipm/160 ipm |
RESOLUTION
Maximum Optical: |
600 x 600 dpi |
Black Output Range: |
100 – 600 dpi |
Color Output Range: |
100 – 600 dpi |
Grayscale Output Bit Depth: |
8 bit |
Color Output Bit Depth: |
24 bit |
INTERFACES/SOFTWARE/ DRIVERS/COMPATIBILITY
Standard Interfaces: |
USB 3.0 |
Optional Interfaces: |
None |
File Formats Supported: |
BMP, JPEG, JPEG2000, PDF, PDF/A, searchable PDF, searchable PDF/A, TIFF |
Bundled Software: |
Panasonic ImageCapture Plus |
Drivers: |
ISIS, SANE, TWAIN, WIA |
Compatibility: |
Windows XP/Server 2003/Vista/Server 2008/7/Server 2012/8/8.1/Server 2016/10, Citrix, Linux |
Embedded Software Platform or Extensible Solutions Interface: |
Not applicable |
COMMENTS
Optional flatbed; RGB LED; auto preview; auto rescan; automatic brightness adjustment; multi color drop out; dynamic threshold; white level from paper; image emphasis; gamma; automtic separation; noise reduction; length control; patch code detection (Type 2, 3, T); control sheet detection; long paper mode up to 100″/2,540 mm; double feed skip; intelligent double feed detection; automatic image orientation; deskew; barcode detection; digital imprinter; auto crop; automatic binary/color distinction; blank page removal; border removal; automatic glass cleaning |
Additional Information
Control Panel: |
Keys |
Dimensions (H x W x D): |
13.54″ x 18.5″ x 17.5″ |
Weight: |
39.2 lbs |
Memory: |
Standard 256 MB |
Power Supply: |
AC power |
Power Requirements (V/Hz): |
100 – 120/50 – 60 |
Battery Life: |
Not applicable |
Energy Used While Power Off (Watts): |
0.3 |
Energy Used in Power Save Mode (Watts): |
1.2 |
Energy Used in Ready Mode (Watts): |
30 |
Max Power Consumption: |
90W |
Energy Star Compliant: |
Yes |
RoHS Compliant: |
Yes |
Warranty: |
Three-year |
Contents: |
CD-ROM, operator manual, roller cleaning paper, quick installation guide, shading paper, USB cable, warranty card |
