Manufacturing Status: Current
Part Number: 1102TX2US0

Domestic Intro Date: June 2018
SRP/Street Price: $2,593/None
Also Sold As: None
Predecessor Model: KYOCERA ECOSYS P7040cdn
Replacement Model:
Replacement Date:
Color Type: 4-color
Controller: KYOCERA
CPU/Bits/MHz: ARM Cortex-A9 dual core/INA/1.2 GHz
Memory (std/max): 1 GB/3 GB
HDD/Storage: Optional 32-GB or 128-GB
PDLs: PCL 5c/6/XL, PostScript 3, XPS
Warm-up Time: 24 sec
First-Page-Out Time (Mono/Color): 5.5 sec/6.5 sec
Mfr/Model/Country: KYOCERA/INA/Vietnam
Monthly Duty Cycle: INA
Rated Engine Life: 150,000 impressions
Recommended Monthly Volume: INA
Standard: 1200 x 1200 dpi
Enhanced: 9600 x 600 dpi
Client OS Support: Windows Server 2008/7/Server 2012/8/8.1/10/Server 2016, Mac OS X v10.5+, Linux
Network Spt: Windows, Mac, Linux
Std Interface: 10/100/1000BaseTX Ethernet, USB 2.0, USB (host) x 2
Opt Interface: 10/100/1000BaseTX Ethernet, 802.11b/g/n
Printer Mgmt: Command Centre RX, KYOCERA NetAdmin, KYOCERA NetViewer
Near Field Communication: No
Embedded Software Platform or Extensible Solutions Interface: Not applicable
Paper Handling
Std/Max Paper Source(s): 2/5
Std/Max Paper Capacity: 600 sheets/2,100 sheets
Paper Size (WxL): 8.5″ x 14″ max
Print Area (WxL): INA max
Paper Weights: 16-lb bond to 90-lb index
Std Output Capacity: 500 sheets
Other Ouput: None
Bypass (Capacity/Weight): 100 sheets/16-lb bond to 120-lb index
Automatic Duplexing: Standard
Collation: Standard
Color Depth (Bits): INA
Color Management: INA
Fonts: 93 PCL, 93 PostScript, 45 Bitmap
IPP (Web) Support: Standard
RIP Once/Print Many: Standard
Other: Direct PDF (encrypted) and XPS print; direct print from USB; supports mobile and cloud printing, Wi-Fi Direct; 1200 x 1200 dpi resolution at reduced speed
Security Specs
Network User Authentication: Yes
IP Address Filtering: Yes
MAC Address Filtering: Yes
HDD Overwrite: Optional
Max Overwrites: 3
HDD Encryption: Optional
Secure Print: Standard
Encrypted Secure Print: Standard
IPsec: Yes
Secure Sockets Layer (SSL): Yes
SNMPv3: Yes
Transport Layer Security: INA
Other: IPv6; opt card authentication kit; opt data security kit encrypts and overwrites data on opt hard drive
Additional Information
Display/Characters: LCD/5 lines
Energy Star Compliance: Yes
Noise Level (Print/Idle): INA
Energy Used While Power Off: 0.1W
Energy Used in Power Save Mode: 0.6W
Energy Used in Ready Mode: 82W
Energy Used While Printing: 643W
Max Power Consumption: 1301W
TEC Value: 2.03KWh
Power Req’s (V/Hz/Amps): 120/60/11.3
Warranty: Three-year
Weight (Base Unit): 88.2 lbs
Dimensions (HxWxD): 18.5″ x 15.4″ x 21″
